HiRes

System Components

CCD camera type E.A.S.Y B-1448-FHC cooled b/w camera
with approx. 1,448,000 pixels,
- Progressive-Scan CCD sensor with large square pixels
- On-Chip integration, signal to noise ratio > 55 dB,
- Binning 2x2, 4x4, 8x8 possible
- Peltier cooling -10°C in ambient of up to 30°C
- Shutter speed 0.02 seconds to 2 hours
- Light-sensitive zoom lens, 2/3’’, 11.5-69 mm, f 1:1,4
- Special set of filters for ethidium bromide applications
  (DNA and UV filters, adapter ring and close-up lens)

RH-5.1 Darkroom hood
- Moveable camera bracket for easy positioning
- Built-in UV-Transilluminator UVT-28 ME-HC on a pull-out rail
  with “High/Low” switching on the front of the hood, High Contrast filter
  size: 22 x 28 cm (8.7 x 11 inches), 312 (302) nm, (other on request)
- Integrated UV protection, even when the hood is open
- Interior illumination (white light), Switches for light sources on
  the front panel
- UV light sources of 254 and 365 nm for epi-illumination
- Special hood sealing to avoid the intrusion of external light

Digital Thermo-Sublimation printer Mitsubishi P 95 DE

Acrylic printer cover and stand for monitor

FireWire Connection

E.A.S.Y^® Win32 Basic Software Module A with camera control software
- Digitalization and camera integration control, Import-/Export functions
- On-Screen visualization of over- and underexposure
- Language selectable: German, English and French
